首頁進口晶振愛普生晶振SG5032VAN156.250000M-KEGA3 156.25M 5032 -40~125℃ 30PPM

SG5032VAN156.250000M-KEGA3 156.25M 5032 -40~125℃ 30PPM

頻率：156.25MHz
尺寸：5032
應　用： SG5032VAN156.250000M-KEGA3156.25M5032-40~125℃30PPM，日本EPSON晶振公司，5032mm晶振,石英晶振，貼片晶振,愛普生晶振,SG5032VAN156.250000M-KEGA3晶振,日本進口晶振,高品質晶振,SG5032晶振,汽車中控屏晶振,汽車音響...

SG5032VAN 156.250000M-KEGA3 156.25M 5032 -40~125℃ 30PPM，日本EPSON晶振公司，5032mm晶振,石英晶振，貼片晶振 ,愛普生晶振,SG5032VAN 156.250000M-KEGA3晶振,日本進口晶振,高品質晶振,SG5032晶振,汽車中控屏晶振,汽車音響控制器晶振，X1G0042610016晶振，X1G0042610027晶振，X1G0042610034晶振

SG5032VAN 156.250000M-KEGA3 156.25M 5032 -40~125℃ 30PPM

代碼	SG5032VAN 156.250000M-KEGA3
頻率	125.000000兆赫
輸出波	LVDS
電源電壓	2.25至3.63伏
尺寸(長×寬×高)	5.00 x 3.20 x 1.20毫米
工作溫度	-40至+85攝氏度
頻率公差	50 ppm
OSC類型	時鐘振蕩器
安裝類型	表面張貼型
型號名稱	SG5032VAN
電流消耗	30.0毫安
頻率老化1	+/-5
頻率老化2	不適用的
對稱	45%至55 %

SG5032VAN 156.250000M-KEGA3 156.25M 5032 -40~125℃ 30PPM

SG5032VAN-EAN

EPSON原廠編碼	型號	頻率	尺寸	輸出
X1G0042610001	SG5032VAN	100.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610002	SG5032VAN	125.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610003	SG5032VAN	125.006250 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610005	SG5032VAN	200.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610006	SG5032VAN	156.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610007	SG5032VAN	400.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610008	SG5032VAN	106.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610009	SG5032VAN	212.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610010	SG5032VAN	74.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610011	SG5032VAN	148.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610012	SG5032VAN	75.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610013	SG5032VAN	150.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610015	SG5032VAN	312.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610016	SG5032VAN	312.515625 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610017	SG5032VAN	161.132800 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610020	SG5032VAN	125.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610021	SG5032VAN	125.006250 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610023	SG5032VAN	100.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610024	SG5032VAN	200.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610025	SG5032VAN	400.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610026	SG5032VAN	106.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610027	SG5032VAN	212.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610028	SG5032VAN	74.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610029	SG5032VAN	148.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610030	SG5032VAN	75.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610031	SG5032VAN	150.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610033	SG5032VAN	156.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610034	SG5032VAN	312.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610035	SG5032VAN	312.515625 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610036	SG5032VAN	161.132800 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610039	SG5032VAN	125.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610040	SG5032VAN	125.006250 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610042	SG5032VAN	100.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610043	SG5032VAN	200.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610044	SG5032VAN	400.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610045	SG5032VAN	106.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610046	SG5032VAN	212.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610047	SG5032VAN	74.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610048	SG5032VAN	148.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610049	SG5032VAN	75.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610050	SG5032VAN	150.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610052	SG5032VAN	156.250000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610053	SG5032VAN	312.500000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610054	SG5032VAN	312.515625 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610055	SG5032VAN	161.132800 MHz	5.00 x 3.20 x 1.20 mm	LVDS
X1G0042610058	SG5032VAN	125.000000 MHz	5.00 x 3.20 x 1.20 mm	LVDS
